The new control and indicator device

  • Easy handling with single hole mounting
  • 360° switching angle
  • IP42 dust- and waterproof
  • Exchangeable BA9s lamp (max. Ø10 mm)

The new KGD40

  • Reduced arcing time
  • Compact design
  • Not polarity sensitive
  • Up to 1000 V


The new KGD40-switch type has been developed as DC switch for applications up to 50 A. The arcing time has been reduced to some milliseconds using permanent magnets in the contact body. 2 magnets per pole are used to ensure not polarity sensitivity. Up on request the switch disconnectors are available with door clutch systems and padlock devices.

Datasheet



A25 Switch

The A25-switch type has been designed for applications where available depths behind the mounting plates are limited and the switching programs require a large number of contacts.


Main features:

  • 25 A switch with up to 48 contacts
  • Up to 24 switching positions
  • IP20 terminal protection cover available
  • Fast on lugs (A25-4)
  • Wide range of optional extras are available


Catalog: A-Switches
Datasheet
